Industrial Ethernet Switch

Industrial 5*10/100M TX (OPT-GY1005)

OPT-GY1005 series support IEEE 802.3 and IEEE802.3u with 10/100M full/half-duplex, MDI/MDI-X auto-sensing. The OPT-GY1005 switches provide 12~48VDC power supply. These switches are specially designed for harsh industrial environments certified by UL508 and UL Class 1 Div 2 certifications.
    ●Green Ethernet solution with ultra low power consumption design
    ●Both standard and wide operating temperature
    ●Complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3x auto-negotiation
    ●Supports auto MDI/MDIX function
    ●Status LED for easy monitoring of device status
    ●Support max forwarding packet length 1552/1536 bytes option
    ●IP40 protection class
    Interface
    5 x Ethernet port (RJ45) 10/100Base-Tx
    Ethernet Port
    Standard: IEEE802.3, IEEE802.3u, IEEE802.3x
    Available speed: force 10Mbps, force 100Mbps and auto-detective 10/100Mbps Full-Duplex and Half-Duplex   auto-negotiation
    Connectors: RJ-45 Connector; MDI/MDI-X connection auto-sensing
    Switch Properties
    MAC Table: 2K
    Packet Buffer: 1Mbit
    Switching Delay: <5μs
    LED Indicators Power, Speed, TX Link/Act
    Power Requirement
    Input: 12VDC~48VDC
    Consumption:3.5W
    Overload Protection: Support
    Reverse Connection Protection: Support
    Redundancy Protection: Support
    Physical Characteristics
    Housing: Metal enclosure
    Protection Class: IP40
    Dimensions: 36 x 120 x 103mm
    Weight: 0.4kg
    Installation: DIN-Rail or Panel mounting
    Environmental Limits
    Operating Temperature: -40°C to 85°C
    Storage Temperature: -40°C to 85°C
    Operating Humidity: 10% to 95% RH (non-condensing)
    Storage Humidity: 5% to 95% RH (non-condensing)
    Industrial Standard
    EMI: FCC/CE/LVD/EMC
    EMS:
    IEC61000-4-2 (ESD): ±8kV (contact), ±15kV (air)
    IEC61000-4-3 (RS): 10V/m (80MHz-2GHz)
    IEC61000-4-4 (EFT): Power Port: ±4kV; Data Port: ±2kV
    IEC61000-4-5 (Surge): Power Port: ±2kV/DM, ±4kV/CM; Data Port: ±2kV
    IEC61000-4-6 (CS): 3V (10kHz-150kHz); 10V (150kHz-80MHz)
    IEC61000-4-16 (Common mode conduction): 30V (cont.), 300V (1s)
    Shock: IEC 60068-2-27
    Free Fall: IEC 60068-2-32
    Vibration: IEC 60068-2-6
    Warranty 5 years
    Model No. Description
    OPT-GY1005 5*10/100Base-Tx, RJ45, 100m, Industrial
    File Name : Format: Size: Download:
    OPT-GY1005 PDF 274.53 KB
